Schneider Electric Intelligent Positioner SRD991 Intelligent Positioner
Create an account to install this asset package.
Maintenance Plans for Schneider Electric Intelligent Positioner Model SRD991 Intelligent Positioner
Integrate maintenance plans directly into your work orders in MaintainX.
Electronics Unit Removal
Safety Precautions
Ensure air supply is turned off to prevent bursting of parts
Removal of Electronics Unit
Pull off the travel indicator 12
Loosen the 7 screws on the front of the electronics unit 40
Lift the electronics unit vertically upward
Disconnect the plugs from the board
Installation of New Electronics Unit
Connect the plugs to the new electronics unit
Plug / IrCom Maintenance
Service Plug Connection
Ensure the service plug (IDC connector) is accessible by pushing cover A to the side.
Verify connection of EDC82 modem
IrCom Option Check
Is the SRD equipped with the IrCom option?
Verify contactless communication via infrared with the positioner.
Software Configuration
Confirm PC software compatibility
Is the configuration of all SRD991 versions possible from the PC?
Parts for Schneider Electric Intelligent Positioner SRD991 Intelligent Positioner
Access the parts list for your equipment in MaintainX.
Hex. Screw With NPT Thread Stainless Steel
522 588 013
Hex. Screw With NPT Thread Plastic
556 446 016
Chimney
534 346 013
Hex. Screw With NPT Thread Stainless Steel
522 588 013
Hex. Screw With NPT Thread Plastic
556 446 016
Chimney
534 346 013
Hex. Screw With NPT Thread Stainless Steel
522 588 013
Hex. Screw With NPT Thread Plastic
556 446 016
Chimney
534 346 013
