KSB SE & Co. KGaA Submersible Motor Pump KRT D 100-316

Ensure the pump set is positioned on a level surface and secured against tipping over.

Verify that the pump set is de-energized and secured against unintentional start-up.

Remove screw plug 903.46 and joint ring 411.46.

Connect the pump set to the power supply.

Secure the pump set against tilting.

Fill in 2.1 oz [60 g] of grease via lubricating nipple 636.02.

Place a suitable container under screw plug 903.33

Ensure the pump set is in a horizontal position

Unscrew both screw plugs 903.34/903.35 with joint rings 411.34/411.35 at the coolant filler openings

Undo screw plug 903.33 with joint ring 411.33 and drain off the coolant

Check the appearance of the drained coolant

Collect and properly dispose of the flushing fluid and any residues of the fluid handled

Wear safety clothing and a protective mask if required

Observe all legal regulations on the disposal of fluids posing a health hazard

Be careful when opening the inner chambers

Place a suitable container under screw plug 903.02

Wear safety clothing and a protective mask if required.

Observe all legal regulations on the disposal of fluids posing a health hazard.

Has the pump been used for handling noxious, explosive, hot or other hazardous fluids?

Flush the pump if it has been used for handling hazardous fluids.

Flush and clean the pump before transporting it to the workshop.

Complete and enclose a certificate of decontamination when returning the pump set.

Check the bail or eyebolt including fasteners (screws/bolts) for any visible damage

Replace any damaged components by original spare parts

Consider reducing the maintenance interval in demanding conditions

Contact KSB Service for consultation or queries
