Ford Vehicle Expedition

Use a suitable tool, for example a screwdriver, to carefully remove the lamp.

Turn the bulb holder counterclockwise and remove it.

Bulb holder removed successfully?

Remove the bulb by pulling it straight out.

To install, reverse the removal procedure.

Warning: Do not apply the brake heavily when you get a flat tire. Gradually decrease your speed and move to a safe place.

Is the flat tire serviced by an authorized dealer?

Note: Replace the spare tire with a road tire as soon as possible.

Did the authorized dealer inspect the system sensor for damage during repair or replacement of the flat tire?

Warning: Only use tire sealants in roadside emergencies as they may cause damage to the tire pressure monitoring system sensor.

Is the tire pressure monitoring system indicator illuminating when the spare tire is in use?

Note: To restore the full function of the tire pressure monitoring system, all road wheels with tire pressure monitoring sensors must be mounted on this vehicle.

Sign off on the flat tire change procedure

Warning: For trained personnel only

Is the 12V battery located in the engine compartment?

Is the vehicle battery maintenance-free?

Does the vehicle battery have a cover and vent hose?

Is the top of the battery clean and dry?

Are the battery cables tightly fastened to the battery terminals?

Is there any corrosion present on the battery or terminals?

Have you neutralized the acid with a solution of baking soda and water?

Have you disconnected the negative battery cable terminal from the battery for storage?

Warning: Brake fluid servicing requires special equipment available at your authorized dealer.

Is this the third year since the last brake fluid change?

If it's not the third year, stop the procedure and schedule for the correct time.

Upload a photo of the old brake fluid

Upload a photo of the new brake fluid

Sign off on the brake fluid change

WARNING: Do not remove the coolant reservoir cap when the engine is on or the cooling system is hot. Wait 10 minutes for the cooling system to cool down. Cover the coolant reservoir cap with a thick cloth to prevent the possibility of scalding and slowly remove the cap. Failure to follow this instruction could result in personal injury.

WARNING: To reduce the risk of personal injury, make sure the engine is cool before unscrewing the coolant pressure relief cap. The cooling system is under pressure. Steam and hot liquid can come out forcefully when you loosen the cap slightly.

Enter the coolant concentration

Is the coolant level between the MIN and the MAX marks on the coolant reservoir?

Note: Coolant expands when it is hot. The level may extend beyond the MAX mark. This is normal.

Maintain coolant concentration within 48% to 50%, which equates to a freeze point between -34°C (-29°F) and -37°C (-35°F). Coolant concentration should be checked using a refractometer. We do not recommend the use of hydrometers or coolant test strips for measuring coolant concentration.

Sign off on the coolant level check
