Ford Pick-Up Truck Ranger

Warning: Only use a recommended wheel and tire cleaner. Contact an authorized dealer for additional information and assistance.

Sponge used to remove heavy deposits of dirt and brake dust

Note: Do not apply a cleaning chemical to warm or hot wheel rims and covers.

Vehicle driven for a few minutes after cleaning the wheels?

Warning: Do not clean the wheels when they are hot.

Note: Some car washes could damage wheel rims and covers.

Warning: Using non-recommended cleaners, harsh cleaning products, chrome wheel cleaners or abrasive materials could damage wheel rims and covers.

Headlamps and rear lamps are off

Tailgate is open to access the rear lamp assemblies

Two bolts from the tail lamp assembly are removed

Lamp assembly is carefully pulled from the tailgate pillar

Electrical connector is disconnected from the bulb

To install, reverse the removal procedure

WARNING: To help prevent your vehicle from moving when changing a wheel, shift the transmission into park (P), set the parking brake and use an appropriate block or wheel chock to secure the wheel diagonally opposite to the wheel being changed. For example, when changing the front left wheel, place an appropriate block or wheel chock on the right rear wheel.

WARNING: The jack supplied with this vehicle is only intended for changing a flat tire in an emergency. Do not attempt to do any other work on your vehicle when it is supported by the jack, as your vehicle could slip off the jack. Failure to follow this instruction could result in personal injury or death.

WARNING: Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to not obstruct the flow of traffic and avoid the danger of being hit when operating the jack or changing the wheel.

WARNING: Only use the jack provided as original equipment with your vehicle.

WARNING: Do not get under a vehicle that is supported by a jack.

WARNING: No person should place any portion of their body under a vehicle that is supported by a jack.

WARNING: Ensure screwthread is adequately lubricated before use.

WARNING: The jack should be used on level firm ground wherever possible.

WARNING: Never place anything between the vehicle jack and the ground.

Rotate the bulb socket counterclockwise and remove it from the rear lamp assembly

Remove the bulb from the bulb socket

To install, reverse the removal procedure

The jack, wheel brace and jack handle are located in the cab.

Note: Not all cab configurations are available in all markets.

5. Lift the jack from the foam block and remove the jack from your vehicle.
