ENERSYS SCR Transformer Type Battery Charger LT2

Warning: Ensure both the AC lines and the battery are disconnected before cleaning.

Connections and terminals clean and tight

No excessive dirt build up on components

Any adjustments bumped or moved during cleaning

Frequency of maintenance based on the environment

Please follow these steps before testing the Transformer:

Connect the charger to AC power.

You will be testing the transformer's windings (with a good quality meter) to check the transformer's voltages.

Your measurements should be within 10% of what is listed on the nameplate.

Second Transformer Test (120V Test)

Disconnect the battery and AC power before testing the fuses.

Using an ohmmeter, set to its x1 scale, test each fuse.

If a fuse tests as an open circuit (infinity), replace it.

If there is continuity across the fuse (less than 1 ohm), it is working properly.

To test if the LEDs are working, turn AC power off then back on.

When the power is turned on, all the LEDs should blink.

Sign off on the AC and DC Fuses Test

Return all replaced components to your service center.

Reconnect all leads exactly as they were removed.

Replace any heat-shrink tubing if any old tubing was removed.

No scratches, gouges, or burrs allowed in the SCR/Diode Block contact area.

No oil, dirt, paint, adhesive or other foreign substances are permitted in the contact area.

Return all replaced components to your service center.

Reconnect all leads exactly as they were removed.

Replace any heat-shrink tubing if any old tubing was removed.

Use the wiring diagrams in the back of this manual to help identify wires connected to the transformer.

Remove the AC input wires from the 3 terminal input blocks.
