Doosan Compressor HP1300WCAT-T4i

WARNING: Do not remove the cap from a HOT engine radiator. The sudden release of pressure from a heated cooling system can result in serious personal injury.

The engine cooling system is filled at the factory with a 50/50 mixture of water and ethylene glycol. This permanent type antifreeze contains rust inhibitors and provides protection to --35° F (--37°C).

The use of such a mixture is recommended for both summer and winter operation. When using water alone, be sure to add a reputable brand of rust inhibitor to prevent internal corrosion.

Is the coolant mixture 50/50 water and ethylene glycol?

Is the coolant mixture providing protection to --35° F (--37°C)?

Is the coolant mixture being used for both summer and winter operation?

Is a reputable brand of rust inhibitor added when using water alone?

It is recommended to test the freezing protection of the coolant every six months or prior to freezing temperatures. Replenish with a fresh mixture every twelve months. A drain for the system is located in the bottom radiator tank. An alternate method would be to disconnect a bottom radiator hose.

Is the freezing protection of the coolant tested every six months or prior to freezing temperatures?

Scavenge Orifice & related parts check

Wheels (bearings, seals, etc) check

Sign off on the compressor maintenance

Compressor Oil Filter Element replaced?

Wheels (bearings, seals, etc) checked?

Fuel Tank (fill at end of day) drained?

Sign off on the compressor maintenance

Warning: This procedure requires trained personnel with PPE!

Trailer secured on adequate capacity jack stands

Adjusting hole cover removed from the adjusting slot on the bottom of the brake backing plate

Brake shoes expanded until the pressure of the linings against the drum makes the wheel very difficult to turn

Starwheel rotated in the opposite direction until the wheel turns freely with a slight lining drag

Adjusting hole cover replaced and wheel lowered to the ground

Procedure repeated on all brakes

Sign off on the brake adjustment

WARNING: Do not remove the cap from a HOT engine radiator. The sudden release of pressure from a heated cooling system can result in serious personal injury.

The engine cooling system is filled at the factory with a 50/50 mixture of water and ethylene glycol. This permanent type antifreeze contains rust inhibitors and provides protection to --35° F (--37°C).

The use of such a mixture is recommended for both summer and winter operation. When using water alone, be sure to add a reputable brand of rust inhibitor to prevent internal corrosion.

It is recommended to test the freezing protection of the coolant every six months or prior to freezing temperatures. Replenish with a fresh mixture every twelve months. A drain for the system is located in the bottom radiator tank. An alternate method would be to disconnect a bottom radiator hose.

Check if the coolant is at the recommended mixture

Check if the rust inhibitor is added when using water alone

Check if the freezing protection of the coolant is tested every six months or prior to freezing temperatures

Check if the system is replenished with a fresh mixture every twelve months
