The Delfield Company Refrigeration Equipment 18691PTB

Remove product from the rail to the refrigerated base

Turn off the rail to save energy and defrost

Ensure the on/off switch is shut off for standard wrapped refrigerated rail units

Ensure the LiquiTec rail is shut off to allow for defrosting

Check the low-pressure control setting for proper rail temperature

Is the thermostat set to maintain the proper rail temperature?

Check if the drain tube is connected to the evaporator drain pan

Ensure the end of the drain tube is in the condensate evaporator in the machine compartment

Is there water accumulation inside the unit?

Is there water collecting underneath the unit?

Unit Leveling and Drain Line Check

Ensure all drain lines are free of obstructions

Clean the interior using soap and warm water

Was soap and warm water sufficient for cleaning?

If necessary, use ammonia and water or a nonabrasive liquid cleaner

Clean the exterior using soap and warm water

Was soap and warm water sufficient for cleaning the exterior?

If necessary, use ammonia and water or a nonabrasive liquid cleaner

Rub with the grain of the stainless steel to avoid marring the finish

Pull the track out to the specified length (1.50” to 2.00” or 3.8cm to 5.0cm)

Line up the rear white roller with the half moon notch in the outer profile

Rotate the track away from the outer track profile to free the intermediate profile

Are the intermediate tracks dishwasher safe?

Clean the intermediate tracks in a sink with detergents and a soft bristle brush if not using a dishwasher

Ensure each roller is thoroughly cleaned

Ensure all acidic items are stored properly

Are all pans in place during operation?

Is the unit operated with minimal door openings?

Is the top section free of overnight storage?

Remove products from pans for overnight storage
