The Delfield Company Refrigeration Equipment 18699BUC

Inspect hinges for looseness or sagging

Tighten screws on hinge brackets if loose

Are doors properly aligned and closing smoothly?

Is there any visible damage to the doors or hinges?

Ensure not to place hot pans on/against the blue ABS liner

Avoid throwing items into the storage area

Remove product from the rail to the refrigerated base

Turn off the rail unit to save energy and defrost

Verify control settings for rail temperature

Ensure the rail on/off switch is turned off at night

Rotate product every four hours to maintain quality

Pull the track out to the specified distance (1.50” to 2.00” or 3.8cm to 5.0cm)

Line up the rear white roller with the half moon notch in the outer profile

Rotate the track away from the outer track profile to free the intermediate profile

Cleaning Intermediate Drawer Tracks

Choose cleaning method for intermediate tracks

Use a soft bristle brush to wash the intermediate track, ensuring each roller is thoroughly cleaned

Check if the drain tube is connected to the evaporator drain pan.

Ensure the end of the drain tube is in the condensate evaporator in the machine compartment.

Is there water accumulation inside the unit?

Is there water collecting underneath the unit?

Unit Leveling and Drain Line Check

Ensure all drain lines are free of obstructions.

Ensure the refrigeration unit is turned off

Gather necessary cleaning tools

Inspect the condenser coil for blockage

Is the condenser coil extremely dirty?

Clean the condenser coil with a vacuum cleaner or stiff brush

Use a condenser cleaner if necessary
