The Delfield Company Refrigeration Equipment 186114BST

Clean the gasket with warm soapy water

Avoid using full strength cleaning products on the gasket

Ensure no sharp tools or knives are used during cleaning

Check if the gasket needs replacement

Remove the old gasket by pulling it out of the groove

Press the new gasket into place

Check if the drain tube is connected to the evaporator drain pan

Ensure the end of the drain tube is in the condensate evaporator in the machine compartment

Is there water accumulation inside the unit?

Is there water collecting underneath the unit?

Unit Leveling and Drain Line Check

Ensure all drain lines are free of obstructions

Understanding Stainless Steel Properties

Acknowledge the properties of stainless steel and its composition

Understand the importance of the chromium protective layer

Ensure the following cleaning materials are available

Confirm no steel pads, wire brushes, or scrapers will be used

Use soap and water for routine cleaning

For extreme stains or grease, use a non-abrasive cleaner and plastic scrub pad

Ensure all acidic items are stored properly

Are all pans in place during operation?

Is the unit operated with minimal door openings?

Are products removed from pans for overnight storage?

Ensure pans remain in unit while empty

Pull the track out to 1.50” to 2.00” (3.8cm to 5.0cm)

Line up the rear white roller with the half moon notch in the outer profile

Rotate the track away from the outer track profile to free the intermediate profile

Choose cleaning method for intermediate tracks

Wash the intermediate track ensuring each roller is thoroughly cleaned
