The Delfield Company Refrigeration Equipment 18660PTB

Inspect hinges for looseness or sagging

Tighten screws on hinge brackets if loose

Are the doors properly aligned and closing smoothly?

Is there any visible damage to the doors or hinges?

Ensure no hot pans are placed on/against the blue ABS liner

Avoid throwing items into the storage area

Check if the drain tube is connected to the evaporator drain pan.

Ensure the end of the drain tube is in the condensate evaporator in the machine compartment.

Is there water accumulation inside the unit?

Is there water collecting underneath the unit?

Unit Leveling and Drain Line Check

Ensure all drain lines are free of obstructions.

Clean the interior with soap and warm water

Was soap and warm water sufficient for cleaning?

Use ammonia and water or a nonabrasive liquid cleaner if necessary

Clean the exterior with soap and warm water

Was soap and warm water sufficient for cleaning the exterior?

Use ammonia and water or a nonabrasive liquid cleaner if necessary

Rub with the grain of the stainless steel

Pull the track out to the specified length (1.50” to 2.00” or 3.8cm to 5.0cm)

Align the rear white roller with the half moon notch

Rotate the track away from the outer track profile to free the intermediate profile

Cleaning Intermediate Drawer Tracks

Are the intermediate drawer tracks dishwasher safe?

Clean the intermediate tracks in a dishwasher or sink with detergents and a soft bristle brush

Ensure each roller is thoroughly cleaned

Prepare warm soapy water for cleaning

Clean the gasket with warm soapy water

Avoid using full strength cleaning products on the gasket

Ensure no sharp tools or knives are used during cleaning

Check if gasket needs replacement

Remove the old gasket by pulling it out of the groove

Press the new gasket into place
