Burton Medical Medical Light A101FL
Create an account to install this asset package.
Maintenance Plans for Burton Medical Medical Light Model A101FL
Integrate maintenance plans directly into your work orders in MaintainX.
Light Head Rotating Friction Adjustment
Preparation
Remove the pods to access the screws holding the housing together
Remove the screws
Adjustment
Lift the top housing off
Use a wrench to tighten the nuts on each shaft
Rotate the light head to verify correct friction
Reassembly
Re-assemble the housing
1300 Hourly / 12 Monthly Light Maintenance
WARNING
WARNING
Light Maintenance Steps
Remove top housing and clean accessible parts
Check and adjust friction between light head and yoke shaft, if needed
1 Weekly Light Check
WARNING: Maintenance Schedule Suggestion
WARNING: Equipment Functionality
Light Movement Check
Check that the light is easy to move in its range of movement
Check that the light holds its position without drifting
Component Security Check
Check that all components appear secure
Light Extensive Cleaning
Preparation
Ensure the light is turned off and unplugged
Removing Top Housing
Remove pods to access screws (if applicable)
Remove screws holding top and bottom housing together
Lift the top housing off
Cleaning Process
Use a soft cloth to wipe the corners and surfaces
Ensure no components inside the light head are bent or damaged
1800 Hourly / 24 Monthly Light Maintenance
WARNING: Maintenance Schedule Suggestion
WARNING: Equipment Malfunction
Spring Arm Tension
Check spring arm tension
Adjust spring arm tension if needed
Clean Optics
Bolts in Ceiling / Wall
Check bolts in ceiling / wall
Tighten bolts in ceiling / wall if needed
Parts for Burton Medical Medical Light A101FL
Access the parts list for your equipment in MaintainX.
Bulb (A100 / A200); Halogen, 35W (37W) IRC, 12V, Bi-Pin, GY6.35 Base
1017111 PK
AIM 50 / AIM 100 / AIM 200; 230V, 240V Version: Fuse T, 1A, 250V, 5x20mm
1017229
Window (A100 / A200)
1017042
Reflector
1019000
Disposable Cover
0008100PK
Bulb (A100 / A200); Halogen, 35W (37W) IRC, 12V, Bi-Pin, GY6.35 Base
1017111 PK
AIM 50 / AIM 100 / AIM 200; 230V, 240V Version: Fuse T, 1A, 250V, 5x20mm
1017229
Window (A100 / A200)
1017042
Reflector
1019000
Disposable Cover
0008100PK
Bulb (A100 / A200); Halogen, 35W (37W) IRC, 12V, Bi-Pin, GY6.35 Base
1017111 PK
AIM 50 / AIM 100 / AIM 200; 230V, 240V Version: Fuse T, 1A, 250V, 5x20mm
1017229
Window (A100 / A200)
1017042
Reflector
1019000
Disposable Cover
0008100PK
