Atlas Copco Dryer FX 110

Release the pressure in the dryer by pressing the condensate drain “TEST” pushbutton located on the steam trap Ref. 2 Fig. 10

Switch the rocker switch to “0” position Ref. 3 Fig. 10

Turn off the supply using the disconnector switch Ref. 4 Fig. 10

Switch the rocker switch to '0' position (Ref. 3 Fig. 10)

Turn off the supply using the disconnector switch (Ref. 4 Fig. 10)

Remove the panels (Ref. 5 Fig. 10)

Clean the condenser fins (Ref. 1 Fig. 10) with compressed air

Close the panels (Ref. 5 Fig. 10)
