True Food Service Equipment Freezer T-23

WARNING: Disconnect power to cabinet before replacing light bulbs

Refer to Image 1 & 2 for guidance

IDL (Integrated Door Lighting) Replacement

Squeeze the plastic lampshield together and pull away from the door

Push the bulb down while pulling the spring activated lampholder up

Ensure all required tools are available

Select the model type for grill removal instructions

Refer to Image 1 for Slide Door Models

Refer to Image 2 for Swing Door Models

CAUTION: Do not use any steel wool, abrasive or chlorine based products to clean stainless steel surfaces.

Understanding Stainless Steel Opponents

Ensure no scratches from wire brushes, scrapers, or steel pads are present.

Check for deposits left on stainless steel surfaces and remove them immediately.

Verify that no chlorides from table salt, food, or water are present on the surfaces.

Preventing Rust on Stainless Steel

Use non-abrasive cleaning tools like soft cloths and plastic scouring pads.

Clean along the polish lines or grain of the stainless steel.

Use alkaline, alkaline chlorinated, or non-chloride containing cleaners.

Disconnect the electrical power to the unit

Clean the finned condenser coil

Vacuum or brush the dirt, lint, or debris from the finned condenser coil

Blow out the condenser with compressed air if there is significant dirt build-up

Reconnect the electrical power to the unit

Contact TRUE Manufacturing Service Department if you have any questions
