Trane Blower Coil Air Handler BCHD090A1A10A2
Create an account to install this asset package.
Maintenance Plans for Trane Blower Coil Air Handler Model BCHD090A1A10A2
Integrate maintenance plans directly into your work orders in MaintainX.
1 Weekly Equipment Check
Safety Precautions
Disconnect all electrical power including remote disconnect
Discharge all energy storing devices such as capacitors
Follow proper lockout/tagout procedures
Secure rotor to prevent freewheeling
Visual Inspection
Observe unit for any change in running condition
Listen for unusual noise
Post Inspection
3 Monthly Equipment Check
Warning! Hazardous Service Procedures!
Acknowledge understanding of safety warnings
Safety Precautions
Disconnect all electrical power including remote disconnects
Discharge all energy storing devices such as capacitors
Follow proper lockout/tagout procedures
Is a qualified licensed electrician present for live electrical work?
Rotating Components Precautions
Disconnect all electric power, including remote disconnects
6 Monthly Fan Sections Inspection
Rotating Components Warning
Pre-Inspection Safety Measures
Disconnect all electrical power to the unit
Secure rotor to prevent freewheeling
Cleaning Procedure
Wear appropriate personal protective equipment
Remove any contamination
Vacuum the section with a HEPA filter vacuum device
Clean contaminated areas with a mild bleach and water solution or EPA-approved sanitizer
Porous Surfaces Cleaning
Safety Precautions
Disconnect all electrical power to the unit
Follow lockout/tagout procedures
Cleaning Process
Wear appropriate personal protective equipment
Use a vacuum device with a HEPA filter to remove accumulated dirt and organic matter
Confirm the drain line is open following the cleaning process
Post-Cleaning Procedures
Allow the unit to dry thoroughly before putting it back into service
1 Yearly Equipment Check
Warning! Hazardous Service Procedures!
Acknowledge understanding of safety warnings
Safety Precautions
Disconnect all electrical power including remote disconnects
Discharge all energy storing devices such as capacitors
Follow proper lockout/tagout procedures
Secure rotor to prevent freewheeling
Inspection and Maintenance
Inspect the unit casing for chips and corrosion
Parts for Trane Blower Coil Air Handler BCHD090A1A10A2
Access the parts list for your equipment in MaintainX.
10K NTC Thermistor
X13790374010
10K NTC Thermistor
X13790374010
10K NTC Thermistor
X13790374010
