Trane Blower Coil Air Handler BCHD036B1A10A2
Create an account to install this asset package.
Maintenance Plans for Trane Blower Coil Air Handler Model BCHD036B1A10A2
Integrate maintenance plans directly into your work orders in MaintainX.
Fan Wheel Set Screws Check
Safety Precautions
Disconnect all electric power, including remote disconnects
Follow proper lockout/tagout procedures
Fan Wheel Set Screws Inspection
Check if the fan wheel set screws are properly adjusted
Refer to Table 44 for recommendations and note any adjustments made
Post-Inspection
Was the component removed or adjusted?
Recheck the fan wheel set screws if any component was removed or adjusted
1 Yearly Equipment Check
Warning! Hazardous Service Procedures!
Acknowledge understanding of safety warnings
Safety Precautions
Disconnect all electrical power including remote disconnects
Discharge all energy storing devices such as capacitors
Follow proper lockout/tagout procedures
Secure rotor to prevent freewheeling
Inspection and Maintenance
Inspect the unit casing for chips and corrosion
3 Monthly Equipment Check
Warning! Hazardous Service Procedures!
Acknowledge understanding of safety warnings
Safety Precautions
Disconnect all electrical power including remote disconnect
Discharge all energy storing devices such as capacitors
Follow proper lockout/tagout procedures
Is a qualified licensed electrician present for live electrical work?
Rotating Components Precautions
Disconnect all electric power, including remote disconnects
Coil Maintenance
Preparation for Winterization
Identify coil type
Locate 'Service Model No of Coil' on the coil section nameplate
Is the coil type suitable for winterization?
Winterization Process
Remove the vent and drain plugs
Blow the coil out with compressed air
Fill and drain the coil several times with full strength glycol
Drain the coil out as completely as possible
Fan Motor Inspection
Safety Precautions
Disconnect all electric power, including remote disconnects
Follow proper lockout/tagout procedures
Fan Motor Inspection
Check for excessive vibration
Check for excessive temperature
Parts for Trane Blower Coil Air Handler BCHD036B1A10A2
Access the parts list for your equipment in MaintainX.
10K NTC Thermistor
X13790374010
10K NTC Thermistor
X13790374010
10K NTC Thermistor
X13790374010
