SEW eurodrive Electric Motor CT90L4
Create an account to install this asset package.
Maintenance Plans for SEW eurodrive Electric Motor Model CT90L4
Integrate maintenance plans directly into your work orders in MaintainX.
2 Yearly Brake Inspection
8.1 Inspection and maintenance intervals
Use only genuine spare parts in accordance with the valid parts list
Install a new brake control system when replacing the brake coil
Ensure motors are not hot to avoid burns
Secure hoist drives or lower them to prevent falling
Isolate the motor and brake from the supply to prevent unintentional power-up
Brake types applicable for inspection
Document the calculated inspection/maintenance intervals based on project planning documents
Inspection Procedure
3000 Hourly Brake Inspection
8.1 Inspection and maintenance intervals
Ensure the following safety precautions are taken
Inspect the following brake components
BMG02 Brake Inspection (Sec. 8.4)
Isolate the motor and brake from the supply
Unscrew the hand lever, remove the fan guard and the fan
Loosen screws and remove the complete brake with the releasing lever
Measure the thickness 'd' of the brake disk
Is the brake disk thickness above the minimum value?
Braking Torque Adjustment
Changing the braking torque for BR03 brake
Isolate the motor and brake from the supply, safeguarding them against unintentional power-up
Unscrew the hand lever, remove the fan guard and the fan
Loosen the screws and remove the complete brake with the releasing lever
Loosen the screws and remove the guide ring with friction plate, brake disc, pressure plate and damping plate
Remove the brake springs from the brake coil body and replace them with new ones
Position the new brake springs symmetrically
Slide the damping plate over the studs attached to the pressure plate with the embossing pattern facing the pressure plate
Place the pressure plate on the brake springs with the damping plate, ensuring correct positioning
Anticorrosion Coating Maintenance
8.1 Inspection and maintenance intervals
Check the condition of the anticorrosion coating
Is the coating intact and free from corrosion?
Touch up the surface coating if minor scratches are present
Renew the anticorrosion coating if significant wear is detected
Initial Startup Check
6.1 Prerequisites for startup
Before startup, ensure the following conditions are met
During startup, ensure the following conditions are met
Parts for SEW eurodrive Electric Motor CT90L4
Access the parts list for your equipment in MaintainX.
Carrier Plate For Installation Integrated In The Motor According To The ECOFAST Specification; Obtain From SEW-EURODRIVE
0187 390 3
BMG02 Brake 24 VDC 0.8 Nm
0574 319 2
BMG02 Brake 24 VDC 1.2 Nm
0574 323 0
BMG02/HR Brake 24 VDC 0.8 Nm
0574 327 3
BMG02/HR Brake 24 VDC 1.2 Nm
0574 331 1
Carrier Plate For Installation Integrated In The Motor According To The ECOFAST Specification; Obtain From SEW-EURODRIVE
0187 390 3
BMG02 Brake 24 VDC 0.8 Nm
0574 319 2
BMG02 Brake 24 VDC 1.2 Nm
0574 323 0
BMG02/HR Brake 24 VDC 0.8 Nm
0574 327 3
BMG02/HR Brake 24 VDC 1.2 Nm
0574 331 1
Carrier Plate For Installation Integrated In The Motor According To The ECOFAST Specification; Obtain From SEW-EURODRIVE
0187 390 3
BMG02 Brake 24 VDC 0.8 Nm
0574 319 2
BMG02 Brake 24 VDC 1.2 Nm
0574 323 0
BMG02/HR Brake 24 VDC 0.8 Nm
0574 327 3
BMG02/HR Brake 24 VDC 1.2 Nm
0574 331 1
