Krowne Direct Draw Cooler DB84

Removing the Stainless Steel Top

Does the unit have a stainless steel top?

Locate hex screws on the underside of the stainless steel top and unscrew with a 1/4” hex screwdriver.

Unscrew the (3) 3/8” hex screws located on the top frame of each door using a 3/8” hex screwdriver.

Lift stainless steel top up to remove.

Align new door with the bottom hinge and re-screw the top (3) 3/8” hex bolts to secure the door.

Place the stainless steel top back onto the unit and secure with the 1/4” hex bolts.

Apply pressure to the bottom of the clip and slide out to remove

Set desired height using the numbered slots on the pilaster strips

Adjust all clips to the same number on the pilaster strips

Insert the top part of the clip into the slot

Apply pressure to the bottom half of the clip until the clip snaps into place

Use mild detergent and warm water

Cleaning the Cooler Interior and Doors

Remove the eight 32 x 1/2” Phillips head screws located on the top and bottom bracket of your existing door handle.

Remove the handle and set the screws aside for reuse.

Slide the handle rod into the bottom bracket and top bracket.

Insert the lock at an angle into the slot on the backside of the top bracket.

Is the lock positioned facing down?

Align the top bracket with the holes on the top of the door and secure with existing screws.

Power Down and Remove Existing Light

Reconnect wires with wires from the new light

Reattach the electrical connector to the new wires
