Ensure connections are properly made

Power up the controller by connecting AC then standby battery

Did the system complete its self-test successfully?

Verify printed information based on board type

View maximum user information using the Host PC software

Ground yourself by touching the controller enclosure or power supply

Turn off all controller system power by removing connectors for both AC power and the standby battery

Disconnect the main power to the controller

Remove the AC fuse located on the power supply

Remove the screws anchoring the CCM circuit board

Ensure connections are properly made

Did the system complete the self-test successfully?

Verify printed or displayed information

Configuration and Options Check

Select method to request configurations and options information

Attach a printer to the Controller or ensure the Controller is attached to a Host PC

Power the system up by connecting the AC power and then the standby battery

Verify the system goes through its self-test and prints the configuration information

Check the printed Expansion Inputs value

Verify the controller version and recognized expansion inputs

Check the Options section for the line indicating the number of AEB8s installed

Use Command 88*2 from the ScramblePad or Host PC software to request Max Users and Options information

If the correct information doesn’t appear on the printouts, power down the Controller and recheck the EBIC connections, then retry the test procedure

Connect a printer to the controller

Temporarily connect a ScramblePad at the Controller if not already installed

Turn on all disabled RQEs to observe their response

Press START 10 * 1 * 100 * 65 #

Enter the test code from each permanently installed ScramblePad
