Identiv RFID Reader Module DTLM2

Is the controller's CCM firmware version 7.5.37 or later?

Update the CCM firmware if necessary.

Disconnect the battery backup power from the controller.

Disconnect the AC power cables to the controller.

Disconnect the following cables and wires from the existing SNIB or SNIB2 board

Did the system print/display the self-test information?

Attach a printer to the Controller or ensure the Controller is attached to a Host PC

Power the system up by connecting the AC power and then the standby battery

Verify the system goes through its self-test and prints the Configuration section

Check Expansion Inputs printed on the local printer

Verify the controller version and recognized expansion inputs

Check the Options section for the line AEB8-N

Use Command 88*2 from the ScramblePad or Host PC software to request Max Users and Options information

If the correct information doesn’t appear on the printouts, power down the Controller and recheck the EBIC connections, then retry the test procedure

Press START 10 * 1 * 100 * 65 #

Complete the testing by entering the test code from each permanently installed ScramblePad

Press START 99 # to quit programming mode upon completion of testing

Contact Identiv (or your dealer) and order part number MPB1.

After the new memory battery arrives, take it and a small wire cutter to the Mx controller.

Open the Mx controller’s enclosure, and locate the existing memory battery.

Ensure the controller’s power remains on during the replacement.

Carefully unplug the memory battery connector from the controller’s main board at location BAT1.

Use a small wire cutter to cut through the existing cable tie and remove it.

Replace the old memory battery with the new one, and plug in its connector at location BAT1 ensuring the red positive wire is on the left side.
