Identiv RFID Antenna DS47L

Attach a printer to the Controller or ensure the Controller is attached to a Host PC

Power up the controller by connecting AC then standby battery

Verify system self-test printout

Check if the system self-test information is printed out at a local printer

Identify the type of MEB and verify the printed information

If networked, view maximum user information using Host PC software

If correct information doesn’t appear on printouts, power down the Controller and recheck EBIC-5 connections

Contact Identiv (or your dealer) and order part number MPB1.

After the new memory battery arrives, take it and a small wire cutter to the Mx controller.

Open the Mx controller’s enclosure, and locate the existing memory battery.

Ensure the controller’s power remains on during the replacement.

Carefully unplug the memory battery connector from the controller’s main board at location BAT1.

Use a small wire cutter to cut through the existing cable tie and remove it.

Replace the old memory battery with the new one, and plug in its connector at location BAT1.

Press START * # to request a status check from the ScramblePad.

Request Specific Relay and Line Module Input Status

Enter the door relay/line module input number (1 - 8) to request specific status.

Press START * [door relay/line module input] # to request status.

Read the status from the ScramblePad LEDs as per Table 7-13.

Refer to “Troubleshooting the Controller Using Status LEDs” on page 7-379 for troubleshooting guidance.

Ground yourself by touching the controller enclosure or power supply to remove any potential static electricity.

Turn off all controller system power by removing connectors for both AC power and the standby battery.

Remove the screws anchoring the CCM circuit board.

Remove the old CCM by grabbing the circuit board by the edges and pulling it up and away from the controller board.

Attach a printer to the Controller or ensure the Controller is attached to a Host PC

Power the system up by connecting the AC power and then the standby battery

Verify the system goes through its self-test and prints the Configuration section

Check Expansion Inputs printed on the local printer

Verify the controller version and recognized expansion inputs

Check the Options section for the line AEB8-N

Request Max Users and Options information using Command 88*2 from the ScramblePad or Host PC software

If the correct information doesn’t appear on the printouts, power down the Controller and recheck the EBIC connections, then retry the test procedure
