Identiv RFID Antenna DS47L-SPX

Ground yourself by touching the controller enclosure or power supply to remove any potential static electricity.

Turn off all controller system power by removing connectors for both AC power and the standby battery.

Disconnect the main power to the controller.

Remove the AC fuse located on the power supply in the lower left corner of the enclosure.

Remove the screws anchoring the CCM circuit board.

Ensure the controller's CCM firmware version is 7.5.37 or later.

Update the CCM firmware if necessary.

Disconnect the battery backup power from the controller.

Disconnect the AC power cables to the controller.

Disconnect the following cables and wires from the existing SNIB or SNIB2 board

Ensure connections are properly made

Did the system go through its self-test?

Verify printed information under Configurations section

Ensure connections are properly made

Did the system complete the self-test successfully?

Record the printed or displayed information from the self-test

Configuration and Options Check

Is the Expansion Relays count correct based on the number of REB8s installed?

Request status check from ScramblePad

Enter command to request status

Press START * # to display status of relay and line module input

Press START * door relay/line module input (1 - 8) # to request specific status

Verify status of Relay 8 and Alarm 8

Read ScramblePad status reports from LEDs

Refer to troubleshooting guide if needed
