Hardy Process Solutions Weight Processor HI6110

Select Calibration from Configuration menu using down arrow and press Enter

Select Hard Cal from Calibration menu and press Enter

Select Ref Weight value using UP or DOWN button and press Enter

Is the Ref Weight set to 0.0 after removing all live load?

Wait for 12 seconds for reading to stabilize

Press Enter to save Ref Weight value

Power up the instrument to test all connections

Check alignment of gasket onto the back panel

Align back panel and attached gasket to the back of the enclosure

Insert and tighten remaining screws

Select Calibration from the Configuration menu using UP or DOWN button and press ENTER

Select C2 (eCal) and press ENTER to display the C2 Calibration Menu items

Does the displayed number match the actual number of installed load cells?

Check all load cell/point cable connections are securely fastened and not broken

Select Reference Weight using UP or DOWN button

Enter the weight applied to the scale or vessel (in pounds)

Is the applied load between 80% to 100% of the expected weight?

Enter the initial weight reading on the display (in pounds)

Enter the weight reading after applying the load (in pounds)

Did the weight reading increase in the proper direction?

Describe any issues with the weight reading

Calibration of Weight Controller

Ensure all live load weight is removed from the scale

Wait for the scale to stabilize

Turn off vibration and production equipment

Enter the reference weight in the Ref Weight text field

Did the 'Cal Completed OK' message appear?
