Hardy Process Solutions Weight Processor HI6500

Select Calibration from the Configuration menu using the down arrow and press Enter

Select Hard Cal from the Calibration menu and press ENTER

Select Ref Weight value using UP or DOWN button and press ENTER

Wait for 12 seconds for the reading to stabilize

Press ENTER to save the Ref Weight value

Select Do Cal Lo using the DOWN button and press ENTER

Power up the instrument to test connections

Check alignment of gasket with back panel screw holes

Align back panel and attach gasket

Loosely insert screws into locations 1 through 5

Tighten screws 1 through 5 in numerical order

Ensure all pre-calibration procedures are completed

Configure the HI 6300 series instrument (units, decimal point, NumAverages, etc.)

Is the scale system clean and ready to receive product?

Enter the Gravity Correction Factor based on your location

C2 and eCAL Calibration from the Web Page

Enter the number of load cells displayed on the webpage

Enter the reference weight for your application

Ensure all live load weight is removed from the scale

Turn off vibration and production equipment

Enter the reference weight in the Ref Weight text field

Click the Do Cal Lo button to perform hard Cal Zero operation

Did the 'Cal Completed OK' message appear?

Load Cell/Point Input/Output Measurements

Measure the mVDC output from each load cell/point

Enter the mV/V rating of the load cell/point

Enter the weight capacity of the load cell/point in pounds

Is the mVDC output within the expected range based on the weight capacity and mV/V rating?

Enter the current weight reading on the input table

Enter the weight of the load placed on the scale or vessel

Does the weight reading change in the proper direction after placing the load?
