Genie Compact Telehandler GTH-1056

Check and add the differential lubricating oil

Check and add the planetary reduction lubricating oil

Sign off on the Comer Axle Maintenance

Warning: This procedure requires trained personnel with PPE!

Genie specifications require that this procedure be performed quarterly

Replacement or testing of the hydraulic oil is essential for good machine performance and service life

Dirty oil and a clogged suction strainer may cause the machine to perform poorly and continued use may cause component damage

Extremely dirty conditions may require oil changes to be performed more often

For hydraulic oil specifications, refer to Specifications, Hydraulic Specifications

Before replacing the hydraulic oil, the oil may be tested by an oil distributor for specific levels of contamination to verify that changing the oil is necessary

Replace the oil when it fails the test

Refer to Maintenance Procedure, Test or Replace the Hydraulic Oil

Perform Engine Maintenance – 1000 Hours

Engine specifications require that this procedure be performed every 1000 hours

Required maintenance procedures and additional engine information are available in the manufacturer's manuals

Refer to Specifications, Engine Operator and Maintenance Manuals

Charge air cooler entry area - drain lube oil/condensate

Change the differential oil (initial, one-time interval)

Change the hub oil (initial, one-time interval)

Change the differential lubricating oil (initial, one-time interval)

Change the planetary reduction lubricating oil (initial, one-time interval)

Adjust the negative brake (initial, one-time interval)

Sign off on the Dana Axle Maintenance

Inspect and Lubricate the Sequencing Chains - GTH-636, GTH-1256, GTH-1544, GTH-844 and GTH-1056

Genie specifications require that this procedure be performed quarterly

In extremely dusty or hostile environments, it may be necessary to lubricate the chains more often

Maintaining the sequencing chains in good condition is essential to safe operation and good machine performance

Failure to detect damage to the chains could result in a hazardous operating condition

Environments in which Genie Telehandlers operate can vary widely from outdoor moisture and temperature extremes to mildly corrosive or highly corrosive industrial atmospheres, in addition to abrasive exposures such as sand and grit

Dynamic shock loading can impose abnormal loads above the endurance limit of the chains

Examples of dynamic shock loading are:

High velocity movement of load followed by sudden abrupt stops
