Doosan Forklift D160S-5

Hydraulic Oil, Strainer & Breather - Check, Clean, Change

Hydraulic High Pressure Filter - Change

Lift Chains - Test, Check, Adjust

Transmission Oil & Oil Filter - Change;

Air Intake System - Check, Clean

Mast, Carriage, Lift Chains & Attachments - Inspect, Lubricate

Steering Mechanism - Check, Lubricate

Brake Cam Shaft & Slack Adjuster - Lubricate

Battery Terminal - Clean, Inspect

Sign off on the maintenance check

Tilt Cylinders - Check, Adjust, Lubricate

Horn and Lights (If Equipped) - Check

Universal Joint - Inspect, Lubricate

Park the lift truck on a level surface, parking brake applied, transmission in neutral

Raise the carriage high enough to access the drive axle housing level/fill plug with breather

Block the bottom of the carriage with a block of wood to hold the carriage in the raised position

Remove the drive axle housing level/fill plug with breather. Wash them in clean, nonflammable solvent

Place an appropriate container under the axle to catch the oil as it drains. Remove the drive axle housing drain plug

Allow the oil to drain completely out. Discard the old oil according to local regulations

Clean and reinstall the drive axle housing drain plug

Remove planetary hub level/drain/fill plugs. Allow the oil to drain completely out. Reinstall the planetary hub plugs

Steer Wheel Bearings - Reassemble
