Doosan Compressor NHP1500

Battery Connections/Electrolyte Check

Tire Pressure and Surface Check

WARNING: Do not remove the cap from a HOT engine radiator. The sudden release of pressure from a heated cooling system can result in serious personal injury.

The engine cooling system is filled at the factory with a 50/50 mixture of water and ethylene glycol. This permanent type antifreeze contains rust inhibitors and provides protection to --35° F (--37°C).

The use of such a mixture is recommended for both summer and winter operation. When using water alone, be sure to add a reputable brand of rust inhibitor to prevent internal corrosion.

Is the coolant mixture 50/50 water and ethylene glycol?

Does the coolant contain rust inhibitors?

Is the coolant providing protection to --35° F (--37°C)?

It is recommended to test the freezing protection of the coolant every six months or prior to freezing temperatures. Replenish with a fresh mixture every twelve months. A drain for the system is located in the bottom radiator tank. An alternate method would be to disconnect a bottom radiator hose.

Has the freezing protection of the coolant been tested?

Has the coolant been replenished with a fresh mixture?

Warning: This procedure requires trained personnel with PPE!

Jack up trailer and secure on adequate capacity jack stands. Check that the wheel and drum rotate freely.

Remove the adjusting hole cover from the adjusting slot on the bottom of the brake backing plate.

With a screwdriver or standard adjusting tool, rotate the starwheel of the adjuster assembly to expand the brake shoes. Adjust the brake shoes out until the pressure of the linings against the drum makes the wheel very difficult to turn.

Then rotate the starwheel in the opposite direction until the wheel turns freely with a slight lining drag.

Replace the adjusting hole cover and lower the wheel to the ground.

Repeat above procedures on all brakes.

Sign off on the brake adjustment

Air Cleaner Service Indicators Check

Lights (running, brake, & turn) check before towing

Pintle Eye Bolts check before towing

Sign off on the daily compressor maintenance

This unit is equipped with an AIR FILTERS RESTRICTED lamp on the instrument panel, covering both the engine and the compressor. This should be checked daily during operation. If the lamp glows (red) with the unit operating at full speed, servicing of the cleaner element is necessary.

Also weekly squeeze the rubber valve (precleaner dirt dump) on each air cleaner housing to ensure that they are not clogged. NOTICE: Holes or cracks downstream of the air cleaner housing will cause the restriction indicators to be ineffective.

The air filters restricted sensor will automatically reset after the main power switch is flipped to “OFF.”

To service the air cleaners on all units proceed as follows:

1. Loosen outer wing nut and remove with outer element. Inspect red window on special inner wing nut to find small dot. If dot is not visible, remove cotter pin and special wing nut and inner (safety) element.

2. Inspect air cleaner housing for any condition that might cause a leak and correct as necessary.

3. Wipe inside of air cleaner housing with a clean, damp cloth to remove any dirt accumulation, especially in the area where the element seals against the housing.

4. Inspect the primary element by placing a bright light inside and rotating slowly. If any holes or tears are found in the paper, discard this element. If no ruptures are found, the element can be cleaned by one of the following procedures.

5. If a new air filter element is to be used check it closely for shipping damage. To reset the signal indicator in the special wing nut, apply suction to the red window.
