Daikin Indoor Unit Cooling Only Air Conditioner FTKS70MVLT

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Unfasten the 2 hooks of each vertical blade ASSY

Remove the 3 vertical blade ASSYs

When reassembling, connect the 3 vertical blade ASSYs. Fasten the hooks at the connecting points.

Each vertical blade ASSY is united with a drain pan ASSY

Sign off on the Vertical Blade ASSY Removal

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Loosen the screw of the fan motor from the air outlet.

Remove the screw of the fan motor fixing plate (upper).

Unfasten the hook at the front and remove the fan motor fixing plate (upper).

Release the harness from the hook, and remove the screw of the fan motor fixing plate (lower).

Remove the fan motor fixing plate (lower).

When reassembling the fan motor and the fan rotor, provide as much as 5 mm (0.2 inch) of play between the side face of the rotor and the bottom frame.

Insert the fan motor allowing for approx. 5 mm (0.2 inch) of play.

Tighten the fan rotor screw until it stops. Then give the screw one more turn.

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Remove the drip proof plate from the indoor heat exchanger

Remove the screw and release the earth/ground wire

Pull out the indoor heat exchanger thermistor

Remove the screw, and then the wire fixture

Remove the 4 screws on the terminal strip and disconnect the connecting wire

Disconnect the connector [S1] and release the harness from the hook

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

1. Remove the signal receiver PCB.

1) Unfasten the 2 hooks of the shield plate.

2) Open the shield plate and remove it.

The shield plate has 2 hooks at the lower part.

3) Remove the screw, and then the terminal strip.

5) Release the harness from the 2 hooks.

When reassembling, make sure to insert the harness into the hook.

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Number of screws removed from the service cover

Number of screws removed from the front grille

Number of screw covers removed with a flat screwdriver

Number of front grille fixtures removed

4 hooks on the top of the front grille unfastened
