Caterpillar Compact Wheel Loader 914M

- Check DEF Injector every 5000 hours

- Add Engine Coolant Extender 0.4 L (0.11 gal) (depending on S•O•SSM Coolant Sampling Results) every 6000 hours

- Check DEF Manifold Filter Element every 10000 Hours

- Change Engine Collant 21.5 L (5.55 gal) every 12000 Hours;

- Change Transfer Drive Oil.3.2 L (0.85 gal). Changed every 1,000 hours after the initial 500 hour change (i.e., 1,500 hours, 2,500 hours, etc.)

- Change Front Differential and Final Drive Oil. Diff = 7.5 L (1.98 gal), Hub = 1.3 L (0.34 gal) each. Changed every 1,000 hours after the initial 500 hour change (i.e., 1,500 hours, 2,500 hours, etc.)

- Change Rear Differential and Final Drive Oil. Diff = 7.5 L (1.98 gal), Hub = 1.3 L (0.34 gal) each. Changed every 1,000 hours after the initial 500 hour change (i.e., 1,500 hours, 2,500 hours, etc.);

Change Transfer Drive Oil. Sampling Only

Change Front Differential and Final Drive Oil. Sampling Only

Change Rear Differential and Final Drive Oil. Sampling Only

Change Engine Oil / Filter Element. Enter the amount of oil used in liters

Lubricate Machine with Prime Application Grease

Change Hydraulic Filter Element

Sign off on the 500 Hours Loader Maintenance

Sign off on the 3000 Hours Loader Maintenance

Amount of Transfer Drive Oil used

Front Differential and Final Drive Oil changed

Amount of Front Differential Oil used

Amount of Front Final Drive Oil used

Rear Differential and Final Drive Oil changed

Amount of Rear Differential Oil used

Amount of Rear Final Drive Oil used

Sign off on the loader maintenance
