Warning: Personal injury can result from hot coolant, steam and alkali.

At operating temperature, engine coolant is hot and under pressure. Any contact can cause severe burns.

Remove cooling system pressure cap slowly to relieve pressure only when engine is stopped and cooling system pressure cap is cool enough to touch with your bare hand.

Do not attempt to tighten hose connections when the coolant is hot, the hose can come off causing burns.

Cooling System Coolant Additive contains alkali. Avoid contact with skin and eyes.

Use Caterpillar Extended Life Coolant (ELC) when you add coolant to the cooling system.

Mixing ELC with other products will reduce the effectiveness of the coolant. This could result in damage to cooling system components.

If Caterpillar products are not available and commercial products must be used, make sure they have passed the Caterpillar EC-1 specification for premixed or concentrate coolants and Caterpillar Extender.

Note: This machine was filled at the factory with Caterpillar Extended Life Coolant.

Obtained a sample of the engine oil from the engine oil sampling valve located on the engine oil filter housing?

Final Drive Oil Sample - Obtain

Positioned the final drive so that oil drain plug is at the bottom?

Obtained a sample of the final drive oil through the hole for the oil level plug?

Fuel System Primary Filter (Water Separator) Element - Replace

Opened the rear access door on the left side of the machine?

Cooling System Coolant Sample (Level 2) - Obtain

Refer to Operation and Maintenance Manual, “Cooling System Coolant Sample (Level 1) - Obtain” for the guidelines for proper sampling of the coolant.

Obtain the sample of the coolant as close as possible to the recommended sampling interval. Supplies for collecting samples can be obtained from your Cat dealer.

Upload the sample for Level 2 analysis.

For additional information about coolant analysis, refer to Special Publication, SEBU6250, “Caterpillar Machine Fluids Recommendations” or consult your Cat dealer.

Sign off on the coolant sample collection

Warning: Personal injury can result from hot coolant, steam and alkali. At operating temperature, engine coolant is hot and under pressure. The radiator and all lines to heaters or the engine contain hot coolant or steam. Any contact can cause severe burns.

Cooling System Coolant Level - Check

Open the left rear access door.

Check the coolant level of the coolant reservoir. Maintain the coolant level between the “FULL” mark and the “LOW” mark.

If additional coolant is necessary, remove the reservoir cap and add the appropriate coolant solution.

Engine Crankcase Breather - Clean

2. Loosen hose clamp (2) and disconnect outlet hose (1) from breather (3).

3. Remove breather (3) and O-ring seal (4).

4. Wash breather (3) in clean, nonflammable solvent.

5. Inspect O-ring seal (4). If the seal is damaged, install a new seal.

6. Install O-ring seal (4) and clean breather (3).

7. Slide outlet hose (1) on breather (3). Tighten hose clamp (2).
