Zebra Ring Scanner RS419

Remove the finger strap assembly

Remove the set screw with screwdriver

Turn the trigger assembly counter-clockwise until the exit window and scan trigger align

Lift the trigger assembly off the scan assembly

Align replacement trigger assembly with scan assembly

Rotate trigger assembly 1/4 turn clockwise

Tighten the set screw with screwdriver

Press down on the finger strap assembly release tab

Slide the finger strap assembly out of the trigger assembly

Align a new finger strap assembly with the slot in the trigger assembly

Push the finger strap assembly into the trigger assembly until the release tab clicks into place

Insert your index finger through the finger strap. Tighten the strap and press the hook and pile together

Is it required to cut excess finger strap material?

Sign off on the finger strap assembly replacement

Using the alcohol wipes, wipe the housing.

Wipe the scanner exit window periodically with a lens tissue or other material suitable for cleaning optical material such as eyeglasses.

1. Disconnect the RS419 from the WT41N0.

2. Dip the cotton portion of the cotton tipped applicator in isopropyl alcohol.

3. Rub the cotton portion of the cotton tipped applicator back-and-forth across the connector. Do not leave any cotton residue on the connector.

4. Repeat at least three times.
