Wolf Gas Range GR488

Wolf Gas Range GR488

Create an account to install this asset package.

Maintenance Plans for Wolf Gas Range Model GR488

Integrate maintenance plans directly into your work orders in MaintainX.

Burner Grates Cleaning

Check mark

Preparation

Check mark

Ensure the burner is turned off and cool before cleaning.

Check mark

Gather cleaning materials

Check mark

Cleaning Process

Check mark

Clean grates with hot water and liquid detergent using a plastic pad or sponge.

Check mark

Apply a paste of baking soda and water to stubborn stains and scrub gently.

Check mark

Use mild abrasive cleaners sparingly if necessary.

Check mark

Post-Cleaning

Check mark

Rinse grates thoroughly with clean water.

Run this procedureArrow right

Griddle Cleaning

Check mark

Initial Cleaning

Check mark

Use a metal spatula and scrape grease into the grease collection tray.

Check mark

Wipe the surface with a paper towel to remove excess grease or oil after it has cooled.

Check mark

Grease Collection Tray Maintenance

Check mark

Clean grease collection tray after each use.

Check mark

Ensure grease does not accumulate in the tray to prevent fire hazards.

Check mark

Drip Tray Cleaning

Check mark

Remove the drip tray by gently pulling it towards yourself.

Check mark

Clean drip tray with soapy water and a clean cloth.

Run this procedureArrow right

Burner Cap Cleaning

Check mark

Preparation

Check mark

Ensure the burner cap is cool before cleaning

Check mark

Remove the burner cap from the cooktop and place it on a flat surface near the sink

Check mark

Cleaning Process

Check mark

Wash the burner cap in warm water with liquid detergent or mild abrasive cleaners

Check mark

Check for and remove any food residues that may pit or craze the surface

Check mark

Post-Cleaning

Check mark

Ensure no food residues remain on the burner cap

Check mark

Dry the burner cap thoroughly before reattaching to the cooktop

Run this procedureArrow right

Leak Testing

Check mark

Preparation

Check mark

Ensure gas valve is shut off before starting

Check mark

Gather necessary materials: brush and liquid detergent

Check mark

Leak Detection

Check mark

Apply liquid detergent to all gas connections using a brush

Check mark

Observe for bubbles around connections indicating a leak

Check mark

If a leak is detected, shut off the gas valve and adjust connections

Check mark

Recheck connections for leaks after adjustments

Check mark

Post-Testing Cleanup

Run this procedureArrow right

Burner Pan Cleaning

Check mark

Initial Cleaning

Check mark

Wipe with warm water and mild detergent

Check mark

Rinse and dry immediately

Check mark

Degreasing

Check mark

Spray degreaser on a cloth and wipe surface

Check mark

Buff dry immediately to avoid streaking

Check mark

Polishing

Check mark

Apply protective polish in the same direction

Check mark

Hard Water Stain Removal

Run this procedureArrow right

Parts for Wolf Gas Range GR488

Access the parts list for your equipment in MaintainX.

Part Name
Part Number

Burner Valve, 15K, Nat

808016

Orifice, Simmer, .62 mm, Marking 62

804128

Orifice, Main, .67 mm, Marking 67

809495

Burner Valve, 15K, LP

808017

Orifice, Simmer / Main, .43 mm, Marking 43

804993

Burner Valve, 15K, Nat

808016

Orifice, Simmer, .62 mm, Marking 62

804128

Orifice, Main, .67 mm, Marking 67

809495

Burner Valve, 15K, LP

808017

Orifice, Simmer / Main, .43 mm, Marking 43

804993

Burner Valve, 15K, Nat

808016

Orifice, Simmer, .62 mm, Marking 62

804128

Orifice, Main, .67 mm, Marking 67

809495

Burner Valve, 15K, LP

808017

Orifice, Simmer / Main, .43 mm, Marking 43

804993
