Toyota Forklift 8FG70U

Inspect cracks, damage and deformation of housing

Inspect cracks, damage and deformation of beam

Measure looseness of axle beam in vehicle longitudinal direction

Inspect damage of power steering hose

Inspect knuckle for cracks and deformation

Sign off on the maintenance inspection

Engine coolant for Super LLC replaced

Enter the current hours of SAS swing lock cylinder

SAS swing lock cylinder replaced after 10000 hours

Enter the current hours of 1KD Timing belt

1KD Timing belt replaced after 4000 hours

Inspect headguard for cracks at welded portion

Inspect headguard for deformation and damage

Tighten Loosening of mounting in back-rest

Inspect back-rest for deformation, crack, and damage

Inspect Function and mounting condition of the lighting system

Inspect Function and mounting condition of the horn

Inspect Function and mounting condition of the direction indicator

Inspect Function and mounting condition of the back up buzzer

Inspect Abnormality of fork and stopper pin

Inspect Misalignment between left and right fork fingers

Inspect Deformation and damage of each part and crack at welded part

Inspect Mast and Lift Bracket for deformation and damage of each part and crack at welded part

Inspect Mast and lift bracket looseness

Inspect Wear, damage, and rotating condition of rollers

Inspect Wear and damage of mast trip

Inspect Tension, deformation, and damage of chain

Inspect State of spark plug (carbon, soot)

Inspect Pinion gear meshing status

Inspect Damage of wiring harness

Sign off on the electrical system inspection
