Toyota Forklift 02 - 5FD14

Inspect for play and looseness in the steering wheel

Inspect the function of the steering wheel

Retighten looseness in mounting of the gear box

Inspect rod, links and arm for looseness and damage

Inspect for oil leaks in the power steering

Inspect for looseness in mounting and linkage of power steering

Inspect for king pin looseness in the knuckle

Sign off on the steering system maintenance

Measure injection timing in fuel system

Inspect draining of sedimenter in fuel system

Inspect oil clutch mechanism function and leak

Measure stall and hydraulic pressure in torque converter and transmission

Clean hydraulic oil tank and oil strainer

Sign off on the 1000 Hours / 6 Months Maintenance

Measure play and reserve in the brake pedal

Inspect the braking effect of the brake pedal

Inspect the operating force of the parking brake

Inspect the braking effect of the parking brake

Inspect for looseness or damage in the parking brake rod and cable

Inspect for leaks, damage, and mounting condition of the brake pipe

Inspect for leaks and fluid level in the reservoir tank

Measure clearance between drum and lining

Sign off on the braking system maintenance

Torque converter oil filter replaced

Cyclone air cleaner element replaced

Brake valve rubber parts replaced

Cups and seals for brake master and wheel cylinders replaced

- Inspect function, wear, damage, leak and mounting looseness in Master cylinder and wheel cylinder

- Inspect Wear of shoe sliding portion and lining

- Inspect Shoe operating condition

- Measure Return spring fatigue

- Inspect Automatic adjuster function

- Inspect Backing plate for deformation, cracks and damage

- Retighten Backing plate loose mounting;
