Toyota Forklift 7FGU25

Inspect for leaks in the differential

Inspect for leaks in the torque converter and transmission

Inspect fluid levels in the torque converter and transmission

Inspect for proper function and looseness in the operating mechanism

Inspect the control valve and clutch functions

Sign off on the power transmission system maintenance

Replace Cups and seals for brake master and wheel cylinders

Sign off on the replacement procedure

Measure play and reserve in the brake pedal

Inspect the braking effect of the brake pedal

Inspect the operating force of the parking brake

Inspect the braking effect of the parking brake

Inspect for looseness or damage in the parking brake rod and cable

Inspect for leaks, damage, and mounting condition of the brake pipe

Inspect for leaks and fluid level in the reservoir tank

Measure clearance between drum and lining

Sign off on the brake system maintenance

Measure tire inflation pressure of the wheels

Inspect for tire cuts, damage, and uneven wearing

Tighten for loose rim and hub nuts

Inspect for metal chips, pebbles, or foreign matter trapped in tire grooves

Inspect rim, side bearing, and disc wheel for damage

Inspect for abnormal sound and looseness in the front wheel bearing

Inspect for abnormal sound and looseness in the rear wheel bearing

Measure for looseness of axle beam in vehicle longitudinal direction while forklift is new

Inspect cracks at fork root and welded part while forklift is new

Inspect wear and damage of mast support bushing

Inspect wear and damage of roller pins
