Toyota Forklift 60 - 5FD20

- Replace Power Steering Rubbers Parts

- Replace Torque Converter Rubber Hoses

- Replace Chains at every 3 years;

Inspect head guard for cracks at welded portions

Inspect head guard for deformation and damage

Retighten for loosening of mounting in the back-rest

Inspect back-rest for deformation, cracks, and damage

Inspect the function and mounting condition of the lighting system

Inspect horn function and mounting condition

Inspect the function and mounting condition of the direction indicator

Inspect the functions of the instruments

Inspect the function and mounting condition of the backup buzzer

- Replace Torque converter oil filter

- Replace Cyclone air cleaner element

- Replace Brake vaIve rubber parts

- Replace Cups and seals for brake master and wheel cylinders;

Inspect for cracks on the distributor cap

Inspect for spark plug burning and measure the gap

Inspect for burning on the distributor side terminal

Inspect for wear and damage on the distributor cap center piece

Inspect pinion gear meshing status

Inspect wiring harness for damage

Measure injection timing in fuel system

Inspect draining of sedimenter in fuel system

Inspect oil clutch mechanism function and leak

Measure stall and hydraulic pressure in torque converter and transmission

Clean hydraulic oil tank and oil strainer

Sign off on the 1000 Hour / 6 Month Maintenance
