Toyota Forklift 42-6FG10

- Measure Valve clearance (IDZ-II·2Z)

- Measure main body compression

- Retighten cylinder head bolt loosening

- Measure injection nozzle injection pressure and spray status

- Inspect radiator rubber mount;

Measure injection timing in fuel system

Inspect draining of sedimenter in fuel system

Inspect oil clutch mechanism function and leak

Measure stall and hydraulic pressure in torque converter and transmission

Clean clogging of relief valve filter

Clean hydraulic oil tank and oil strainer

Sign off on the 1000 Hour / 6 Month Maintenance

Measure battery fluid specific gravity

Inspect open-circuit in open plug

Inspect open-circuit in intake heater

Sign off on the electric system maintenance

Inspect fork and stopper pin for abnormality

Inspect for misalignment between left and right fork fingers

Inspect each welded parts for deformation, damage, and cracks

Inspect mast and lift bracket for looseness

Inspect wear, damage, and rotating condition of rollers

Inspect mast trip for wear and damage

Inspect tension, deformation, and damage of chain

Inspect abnormality of chain anchor bolt

- Inspect function, wear, damage, leak and mounting looseness in Master cylinder and wheel cylinder

- Inspect Wear of shoe sliding portion and lining

- Inspect Shoe operating condition

- Measure Return spring fatigue

- Inspect Automatic adjuster function

- Inspect Backing plate for deformation, cracks and damage

- Retighten Backing plate loose mounting;
