Toyota Forklift 32-8FG20
Need answers fast?
Explore the manual using AI.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Manual for Toyota Forklift 32-8FG20
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
Toyota Forklift 32-8FG20
Create an account to install this asset package.
Maintenance Plans for Toyota Forklift Model 32-8FG20
Integrate maintenance plans directly into your work orders in MaintainX.
250 Hour / 6 Week Drive System Maintenance
Measure wheels tire inflation pressure in drive system
Inspect wheels tire cuts, damage and uneven wearing in drive system
Retighten wheels loose rim and hub nuts in drive system
Measure wheels tire groove depth in drive system
Inspect wheels metal chips, pebbles and other foreign matter trapped in tire grooves in drive system
Inspect wheels rim, side bearing and disc wheel damage
Inspect wheels abnormal sound and looseness of front wheel bearing
Inspect wheels abnormal sound and looseness of rear wheel bearing
2000 Hour / 12 Month Power Transmission System Maintenance
Inspect damage of shift lever cable
Retighten differential bolt loosening
Inspect Looseness at spline connections
Inspect Looseness of universal joint
Inspect Twisting and cracks of axle shaft
Sign off on the power transmission system maintenance
250 Hour / 6 Week Power Transmission System Maintenance
Inspect differential oil level in power transmission system
Inspect differential for leak in power transmission system
Inspect torque converter & transmission oil level in power transmission system
Inspect torque converter & transmission for leak in power transmission system
Inspect torque converter & transmission operating mechanism function and looseness in power transmission system
Measure Clutch pedal play
Inspect Abnormal sound and functioning (connection)
Inspect Clutch master cylinder function and leak
Inspect clutch fluid level
500 Hour / 3 Month Maintenance
Retighten propeller shaft and axle shaft loose joint
Replace engine oil filter
Replace engine coolant
250 Hour / 6 Week Hydraulic System Maintenance
Retighten loosening and damage of cylinder mounting
Inspect deformation and damage of rod, rod screw and rod end
Inspect cylinder operation
Measure natural drop and natural forward tilt
Inspect cylinder for damage and oil leak
Inspect cylinder for wear and damage of pin and pin support
Measure lifting speed
Inspect uneven movement
Inspect oil pump for oil leak and abnormal sound
Parts for Toyota Forklift 32-8FG20
Access the parts list for your equipment in MaintainX.
Electrical Tester
09082-76002-71
Engine Unit Hanger
09010-20111-71
Engine With Transmission Hanger
09010-23320-71
Transmission Bearing Replacer
09150-10170-71
Belt Tension Gage
09216-76002-71
Electrical Tester
09082-76002-71
Engine Unit Hanger
09010-20111-71
Engine With Transmission Hanger
09010-23320-71
Transmission Bearing Replacer
09150-10170-71
Belt Tension Gage
09216-76002-71
Electrical Tester
09082-76002-71
Engine Unit Hanger
09010-20111-71
Engine With Transmission Hanger
09010-23320-71
Transmission Bearing Replacer
09150-10170-71
Belt Tension Gage
09216-76002-71
