Tajima Embroidery Machine TMAR-K1204C-3260

Turn OFF the power switch before cleaning

Press D switch at the tension base twice

Record the number of times cleaned this week

Clean each section using a cleaning tool or air compressor

Was the cleaning cycle completed?

Use the oiler to lubricate the raceway

Use the oiler to lubricate the lubrication hole

Turn OFF the power switch before starting the procedure

Use TAJIMA specified grease or equivalent

Ensure NIG LUBE PG: 300ML is available for use

Inject grease into the following components using a syringe

Turn OFF the power switch before starting the greasing process

Use KING STAR EP NO.2: 400G grease

Apply grease to the ATH cam and steel plate (back of border frame)

Is the greasing process completed successfully?

Turn ON the power switch after completing the greasing process
