Mitsubishi Split-Type Air Conditioner PUZ-A30NHA6
Create an account to install this asset package.
Maintenance Plans for Mitsubishi Split-Type Air Conditioner Model PUZ-A30NHA6
Integrate maintenance plans directly into your work orders in MaintainX.
4-Way Valve Coil,Linear Expansion Valve Coil And Bypass Valve Coil Replacement
(1) Remove the service panel. (See Figure 1)
(2) Remove the top panel. (See Figure 1)
(3) Remove the electrical parts box. (See Photo 3)
[Removing the 4-way valve coil]
(4) Remove 4-way valve coil fixing screw (M4 × 6).
(5) Remove the 4-way valve coil by sliding the coil toward you.
(6) Disconnect the connector 21S4 (green) on the controller board in the electrical parts box.
[Removing the linear expansion valve coil]
(4) Remove the linear expansion valve coil by sliding the coil upward.
High Pressure Switch Replacement
Upload a photo of the service panel before removal
Service panel removed successfully
Upload a photo of the top panel before removal
Top panel removed successfully
Upload a photo of the electrical parts box before removal
Electrical parts box removed successfully
Upload a photo of the right side panel before removal
Right side panel removed successfully
Upload a photo of the lead wire of high pressure switch before removal
Reactor A30/36 Replacement
Remove the service panel
Upload a photo of the service panel after removal
Remove the top panel
Upload a photo of the top panel after removal
Remove the electrical parts box
Upload a photo of the electrical parts box after removal
Remove 4 reactor fixing screws (4 × 10) and remove the reactor
Upload a photo of the reactor after removal
Sign off on the reactor replacement
Compressor Replacement
Remove the service panel
Remove the top panel
Remove 2 front cover panel fixing screws (5 × 12) and remove the front cover panel
Remove 2 back cover panel fixing screws (5 × 12) and remove the back cover panel
Remove the electrical parts box
Remove 3 valve bed fixing screws (4 × 10), 4 ball valve and stop valve fixing screws (5 × 16), then remove the valve bed
Remove 3 right side panel fixing screws (5 × 12) in the rear of the unit and then remove the right side panel
Remove 3 separator fixing screws (4 × 10) and remove the separator
Remove the thermistor <Comp. surface> (TH32)
TH7 Thermistor Replacement
Warning: This procedure should be performed by trained personnel only.
Service panel removed
Top panel removed
Connector TH7 (red) on the controller circuit board disconnected
Clamp for the lead wire in the rear of the electrical parts box loosened
Thermistor <Ambient> (TH7) pulled out from the sensor holder
Note: In case of replacing thermistor <Ambient> (TH7), replace it together with thermistor <2-phase pipe> (TH6), since they are combined together.
Thermistor <2-phase pipe> (TH6) removed
Sign off on the thermistor replacement
Parts for Mitsubishi Split-Type Air Conditioner PUZ-A30NHA6
Access the parts list for your equipment in MaintainX.
Inverter Starter Type, Hermetic Compressor - 1,3 KW
TNB220FLHM
Inverter Starter Type, Hermetic Compressor - 1,3 KW
TNB220FLHM
Inverter Starter Type, Hermetic Compressor - 1,3 KW
TNB220FLHM
