Mitsubishi Split-Type Air Conditioner PUZ-A18NKA7
Create an account to install this asset package.
Maintenance Plans for Mitsubishi Split-Type Air Conditioner Model PUZ-A18NKA7
Integrate maintenance plans directly into your work orders in MaintainX.
Outdoor Unit Refrigirant Charging
Cautions for service
Refrigerant recovered from the unit completely
Refrigerant not released in the air
Cycle charged with specified amount of refrigerant after service
Filter drier installed for new refrigerant
Additional refrigerant charge
Cylinder for R410A is a syphon type
Charging performed with the cylinder of syphon stood vertically
Service tools
Outdoor Unit TH4/TH32/TH33 Thermistors Replacement
Remove the service panel
Upload a photo of the removed service panel
Remove the top panel
Upload a photo of the removed top panel
Remove the front panel
Upload a photo of the removed front panel
Remove the back panel
Upload a photo of the removed back panel
Remove the electrical parts box
Outdoor Unit TH6 And TH3 Thermistors Replacement
Remove the service panel
Upload a photo of the removed service panel
Remove the top panel
Upload a photo of the removed top panel
Remove the front panel
Upload a photo of the removed front panel
Remove the back panel fixing screws, 5 from the right and 2 from the rear side, and detach the back panel
Upload a photo of the detached back panel
Disconnect the connector TH3 (white) or TH6/7 (red) on the controller circuit board in the electrical parts box
Outdoor Unit Compressor Replacement
Remove the service panel
Upload a photo of the removed service panel
Remove the top panel
Upload a photo of the removed top panel
Remove the front panel
Upload a photo of the removed front panel
Remove the back panel
Upload a photo of the removed back panel
Remove the electrical parts box
Outdoor Unit Panels And Grille Replacement
Remove the top panel fixing screws (4 × 10), one from the right and two from the left side, and detach the top panel.
Remove 2 service panel fixing screws (4 × 10) and detach the service panel by pulling it downward.
Remove the front panel fixing screws (4 × 10), 3 from the front, 2 from the right and 2 from the left side, and detach the front panel.
Remove the back panel fixing screws (4 × 10), 5 from the right and 2 from the rear side, and detach the back panel.
Remove 2 grille fixing screws (4 × 10) and detach the grille.
Sign off on the panel and grille replacement
Parts for Mitsubishi Split-Type Air Conditioner PUZ-A18NKA7
Access the parts list for your equipment in MaintainX.
Inverter Starter Type, Compressor - 0,9 KW
SNB130FBCM2
Inverter Starter Type, Compressor - 0,9 KW
