Marathon Electric Motor RJ-225 ULTRA

Create an account to install this asset package.

Maintenance Plans for Marathon Electric Motor Model RJ-225 ULTRA

Integrate maintenance plans directly into your work orders in MaintainX.

3 Monthly Electric Motor Check

Safety Precautions

Ensure the unit is locked-out and tagged-out before starting the procedure

Check functional operation of controls and options

Test the stop button

Verify timers are functioning correctly

Check all indicator lights

Inspect hydraulic components

Check hydraulic cylinder for leakage

Inspect internal hoses and connections for leakage

Run this procedure

Filter Maintenance

WARNING: Lock-out and Tag-out

Filter Removal

Disconnect the union on the suction side of the pump.

Remove the four bolts retaining the suction flange.

Lift the filter from the reservoir.

Filter Cleaning

Clean the filter element with a soft brush and standard industrial solvent.

Filter Replacement

Replace the filter after cleaning.

Run this procedure

1 Yearly Electric Motor Maintenance

WARNING: Lock-out and Tag-out

Ensure the unit is locked-out and tagged-out before starting maintenance

Lubricate Electric Motor Bearings

Lubricate electric motor bearings per manufacturer's instructions

Hydraulic Fluid Maintenance

Change the hydraulic fluid in the entire system

Is existing oil being reused?

If reusing oil, has it been tested by a laboratory to ensure it meets necessary specifications?

Add additives to bring oil back to standards, if necessary

Run this procedure

Cylinder Replacement

Remove access covers

Remove hoses

Remove cylinder pins

Remove cylinders

Install the cylinders by reversing the removal steps

Check that all removed parts are reinstalled correctly

Test the system for proper operation after cylinder installation

Describe any issues encountered during the procedure

Run this procedure

1 Monthly Electric Motor Maintenance

Safety Warning

Never enter any part of the compactor until the unit has been locked-out and tagged-out.

Compactor Clean-Out

Remove access cover(s) and clean debris from behind the compactor ram (for compactors with legs). Replace cover(s) when clean-out is complete.

Open the hinged access cover on each side at the bottom and clean out (for compactors with skids RJ-450 and above). Close hinged cover and fasten when clean-out is complete.

Check external hoses for chafing, rubbing, and other deterioration or damage.

Check for any unsafe conditions in the compactor area.

Hydraulic Reservoir Check

Check oil level in hydraulic reservoir.

Run this procedure
