Marathon Electric Motor RJ225

Create an account to install this asset package.

Maintenance Plans for Marathon Electric Motor Model RJ225

Integrate maintenance plans directly into your work orders in MaintainX.

Filter Maintenance

WARNING: Lock-out and Tag-out

Filter Removal

Disconnect the union on the suction side of the pump.

Remove the four bolts retaining the suction flange.

Lift the filter from the reservoir.

Filter Cleaning

Clean the filter element with a soft brush and standard industrial solvent.

Filter Replacement

Replace the filter after cleaning.

Run this procedure

Limit Switch Adjustment

WARNING: Lock-Out & Tag-Out compactor prior to any service or maintenance.

Retract the ram completely. Lock-out and tag-out compactor.

Mark the ram front position on the compactor side.

Power up the compactor and run the ram forward 3/4”-1” and stop.

Lock-out and tag-out the compactor.

Remove the top cover or side access cover to gain access to the actuator.

Loosen the actuator screws and slide the actuator back against the limit switch arm until the limit switch clicks.

Retighten the screws.

Replace the access cover(s).

Run this procedure

3 Monthly Electric Motor Check

WARNING: Never enter any part of the compactor until the unit has been locked-out and tagged-out.

Check functional operation of controls and options

Test stop button functionality

Verify timers are operational

Check if all indicator lights are functioning

Inspect hydraulic components

Check hydraulic cylinder for leakage

Inspect internal hoses and connections for leakage

Examine hoses for chafing and wear

Run this procedure

Cylinder Replacement

Remove access covers

Remove hoses

Remove cylinder pins

Remove cylinders

Install the cylinders by reversing the removal steps

Run this procedure

1 Monthly Electric Motor Maintenance

Safety Warning

Never enter any part of the compactor until the unit has been locked-out and tagged-out.

Compactor Clean-Out

Remove access cover(s) and clean debris from behind the compactor ram (for compactors with legs). Replace cover(s) when clean-out is complete.

Open the hinged access cover on each side at the bottom and clean out (for compactors with skids RJ-450 and above). Close hinged cover and fasten when clean-out is complete.

Check external hoses for chafing, rubbing, and other deterioration or damage.

Check for any unsafe conditions in the compactor area.

Check oil level in hydraulic reservoir

Is the oil level in the hydraulic reservoir 3/4 of the sight gauge?

Run this procedure
