Kaeser Air Compressor ASD 40S

Warning: Ensure the power supply disconnecting device is switched off and locked in the off position. Check that no voltage is present and the machine has cooled down.

Power supply disconnecting device is switched off and locked in the off position

Do not clean the air filter element with liquids.

Air filter element is not cleaned with liquids

Check that all sealing surfaces match each other. The use of an unsuitable air filter element can permit dirt to ingress the pressure system and cause damage to the machine.

All sealing surfaces match each other

Enter the name of the replacement part used

Warning: Ensure the power supply disconnecting device is switched off and locked in the off position. Ensure no voltage is present and the machine has cooled down.

Power supply disconnecting device is switched off and locked in the off position

Material: Warm water and household detergent

Carefully remove the ventilation grill and take out the filter mat

Beat the mat or use a vacuum cleaner to remove loose dirt

Is it necessary to wash the mat with lukewarm water and household detergent?

Warning: Compressed air and devices under pressure can injure or cause death if the contained energy is released suddenly or uncontrolled.

Warning: Escaping oil mist is damaging to health.

Caution: The machine could be damaged by unsuitable oil. Never mix different types of oil.

The power supply disconnecting device is switched off

The disconnecting device is locked in the off position

A check has been made no voltage is present

Vent all pressurized components and chambers completely

Close the user's shut-off valve between the machine and the compressed air system

Check that the oil separator tank pressure gauge reads 0 psig

Power supply disconnecting device is switched off?

Disconnecting device is locked in the off position?

Used brush and vacuum cleaner to clean the cooler?

Air and oil coolers can no longer be properly cleaned?

If yes, heavy and stubborn contamination should be removed by a KAESER Service representative.

The machine must be isolated from the compressed air system and completely vented before undertaking any work on the pressure system.

The oil circuit vents automatically as soon as the machine is stopped.

Venting takes place in three stages:

■ Isolate the compressor from the compressed air system.

■ Vent air from the oil separator tank.

■ Vent air manually from the air cooler.

Material: The hose coupling, shut-off valve and maintenance hose lie beneath the oil separator tank.

Precondition: The power supply disconnecting device is switched off

The disconnecting device is locked in the off position
