Inoxpa Valve VA47-1-10-06-78-076

Inoxpa Valve VA47-1-10-06-78-076

Create an account to install this asset package.

Maintenance Plans for Inoxpa Valve Model VA47-1-10-06-78-076

Integrate maintenance plans directly into your work orders in MaintainX.

Valve Cleaning

Check mark

CIP Cleaning Process

Check mark

Verify seal material compatibility

Check mark

Select cleaning solution type

Check mark

Check concentration of cleaning solutions

Check mark

Perform final rinse with clean water

Check mark

Alkaline Solution Preparation

Check mark

Measure NaOH for 1% solution (1 kg NaOH + 100 l H2O)

Check mark

Measure NaOH for 33% solution (2.2 l NaOH 33% + 100 l H2O)

Check mark

Acid Solution Preparation

Run this procedureArrow right

Leak Detector Disassembly

Check mark

Disassembly

Check mark

Remove the pin (50) that joins the leak detector drive bushing (17C) to the body (01A)

Check mark

Remove the drive bushing (17C) and the spring (06) through the leak detector upper part and the shaft (08) through the bottom part

Check mark

Remove the O-ring (20A) from the leak detector shaft (08)

Check mark

Remove the O-ring (20D) from the drive bushing (17C)

Check mark

Remove the O-rings (20C,20D) from the leak detector body (01A)

Check mark

Post Disassembly Check

Check mark

Ensure all parts are removed and accounted for

Check mark

Post Disassembly Cleanup

Run this procedureArrow right

Pneumatic Drive Assembly

Check mark

Initial Assembly Steps

Check mark

Place the discs (03,03A) in the open position.

Check mark

Place the actuator connecting rod (04C) on the disc shaft (03A) as shown in the figure 10.011.32.0018.

Check mark

Place the connecting rod (04D) on the disc shaft (03) as shown in the figure 10.011.32.0018 and fix it with the screw (23H).

Check mark

Intermediate Assembly Steps

Check mark

Place the following components

Check mark

Place the nuts (26) and tighten them.

Check mark

Supply compressed air to the actuator.

Check mark

Place the support (21) and the actuator (10) on the actuator connecting rod (04C) and place the pin (50) which joins the connecting rod (04C) to the actuator (10).

Run this procedureArrow right

Leakeage Butterfly Valve Disassembly

Check mark

Safety Precautions

Check mark

Proceed with caution to avoid personal injury.

Check mark

Disconnect the compressed air before starting to disassemble the valve.

Check mark

Read instructions carefully before disassembling the valve clamps.

Check mark

Ensure only qualified persons perform valve and actuator assembly and disassembly.

Check mark

Required Tools

Check mark

Gather the necessary tools for disassembly and assembly

Check mark

Disassembly Steps

Check mark

Loosen the screws (23) joining the flanges (02A) to the half-bodies (02).

Run this procedureArrow right

Leak Detector Assembly

Check mark

O-ring Placement

Check mark

Place the O-ring (20A) on the leak detector shaft (08)

Check mark

Place the O-ring (20D) on the leak detector drive bushing (17C)

Check mark

Place the O-rings (20C,20D) on the leak detector body (01A)

Check mark

Assembly of Leak Detector Components

Check mark

Pass the leak detector shaft (08) with its O-rings through the bottom part of the leak detector body (01A)

Check mark

Place the spring (06) on the leak detector body (01A)

Check mark

Place the leak detector drive bushing (17C) and pass the pin through its hole to fix the shaft

Check mark

Final Touches

Run this procedureArrow right
