Inoxpa Valve VA47-0-77-04-78-040

Inoxpa Valve VA47-0-77-04-78-040

Create an account to install this asset package.

Maintenance Plans for Inoxpa Valve Model VA47-0-77-04-78-040

Integrate maintenance plans directly into your work orders in MaintainX.

Leak Detector Assembly

Check mark

O-ring Placement

Check mark

Place the O-ring (20A) on the leak detector shaft (08)

Check mark

Place the O-ring (20D) on the leak detector drive bushing (17C)

Check mark

Place the O-rings (20C,20D) on the leak detector body (01A)

Check mark

Assembly of Leak Detector Components

Check mark

Pass the leak detector shaft (08) with its O-rings through the bottom part of the leak detector body (01A)

Check mark

Place the spring (06) on the leak detector body (01A)

Check mark

Place the leak detector drive bushing (17C) and pass the pin through its hole to fix the shaft

Check mark

Final Touches

Run this procedureArrow right

Valve Cleaning

Check mark

CIP Cleaning Process

Check mark

Verify seal material compatibility

Check mark

Select cleaning solution type

Check mark

Check concentration of cleaning solutions

Check mark

Perform final rinse with clean water

Check mark

Alkaline Solution Preparation

Check mark

Measure NaOH for alkaline solution (1 kg NaOH + 100 l H2O)

Check mark

Measure NaOH for alkaline solution (2.2 l NaOH 33% + 100 l H2O)

Check mark

Acid Solution Preparation

Run this procedureArrow right

Pneumatic Drive Disassembly

Check mark

Disconnect the compressed air from the actuator

Check mark

Disassemble the upper protectors by unscrewing the screws that join them to the actuator support

Check mark

Remove the screw that joins the bottom protectors and the bottom leak detectors to the valve body

Check mark

Unscrew the screws to separate the fixed bottom protector from the mobile

Check mark

Loosen the screws which join the flanges to the half-bodies

Check mark

Separate the flanges

Check mark

Remove the screws which join the actuator support to the half-bodies

Check mark

Remove the pin which joins the connecting rod to the actuator

Check mark

Remove the screw which joins the connecting rod to the disc shaft

Run this procedureArrow right

Seal Seat Maintenance

Check mark

Preparation

Check mark

Ensure all parts are in perfect condition and free from dirt

Check mark

Lubrication

Check mark

Lubricate the disc shaft with the specified grease

Check mark

Lubricate the seat seal with the specified grease

Check mark

Assembly

Check mark

Insert the long disc spindle into one of the seal holes

Check mark

Stretch the seal to insert the short spindle in the free gasket hole

Check mark

Turn the disc until it is perpendicular to the seal

Run this procedureArrow right

Leakeage Butterfly Valve Disassembly

Check mark

Safety Precautions

Check mark

Proceed with caution to avoid personal injury.

Check mark

Disconnect the compressed air before starting to disassemble the valve.

Check mark

Read instructions carefully before disassembling the valve clamps.

Check mark

Ensure only qualified persons perform valve and actuator assembly and disassembly.

Check mark

Required Tools

Check mark

Gather the necessary tools for disassembly and assembly

Check mark

Disassembly Steps

Check mark

Loosen the screws (23) joining the flanges (02A) to the half-bodies (02).

Run this procedureArrow right
