Inoxpa Valve VA47-1-00-06-78-063

Inoxpa Valve VA47-1-00-06-78-063

Create an account to install this asset package.

Maintenance Plans for Inoxpa Valve Model VA47-1-00-06-78-063

Integrate maintenance plans directly into your work orders in MaintainX.

Manual Drive Assembly

Check mark

Assembly

Check mark

Place components in the open position

Check mark

Place plugs on valve half-bodies

Check mark

Place handle guide on disc shaft

Check mark

Place connecting rods on disc shafts and fix with screws

Check mark

Place plugs on connecting rods

Check mark

Place bushings, washers, and drive arm

Check mark

Place and tighten nuts

Run this procedureArrow right

Control Head C-TOP S Adapter Kit Disassembly

Check mark

Ensure the actuator is without pressure before starting

Check mark

Disassembly

Check mark

Release the compressed air supply

Check mark

Remove the adapter and the air connection on the top part of the actuator

Check mark

Screw the shaft (08A) on the top part of the piston with a 10 mm wrench

Check mark

Insert the adapter (13) supplied with the kit through the shaft (08A)

Check mark

Place the seals (20B,20C,20D) on the core (55)

Check mark

Insert the core (55) in the adapter (13) and screw it on the actuator with a 19 mm wrench

Check mark

Screw the air fitting (18) on the adapter (13)

Run this procedureArrow right

Pneumatic Drive Assembly

Check mark

Initial Setup

Check mark

Place the discs (03,03A) in the open position.

Check mark

Connecting Rod and Disc Shaft Assembly

Check mark

Place the actuator connecting rod (04C) on the disc shaft (03A) as shown in the figure 10.011.32.0018.

Check mark

Place the connecting rod (04D) on the disc shaft (03) as shown in the figure 10.011.32.0018 and fix it with the screw (23H).

Check mark

Bushing and Drive Arm Installation

Check mark

Place the bushings (17C), the washers (25) and the drive arm (04B).

Check mark

Place the nuts (26) and tighten them.

Check mark

Actuator and Support Installation

Run this procedureArrow right

Leak Detector Assembly

Check mark

O-ring Placement

Check mark

Place the O-ring (20A) on the leak detector shaft (08)

Check mark

Place the O-ring (20D) on the leak detector drive bushing (17C)

Check mark

Place the O-rings (20C,20D) on the leak detector body (01A)

Check mark

Assembly of Leak Detector Components

Check mark

Pass the leak detector shaft (08) with its O-rings through the bottom part of the leak detector body (01A)

Check mark

Place the spring (06) on the leak detector body (01A)

Check mark

Place the leak detector drive bushing (17C) and pass the pin through its hole to fix the shaft

Check mark

Final Touches

Run this procedureArrow right

Seal Seat Maintenance

Check mark

Preparation

Check mark

Ensure all parts are in perfect condition and free from dirt

Check mark

Lubrication

Check mark

Lubricate the disc shaft with the specified grease

Check mark

Lubricate the seat seal with the specified grease

Check mark

Assembly

Check mark

Insert the long disc spindle into one of the seal holes

Check mark

Stretch the seal to insert the short spindle in the free gasket hole

Check mark

Turn the disc until it is perpendicular to the seal

Run this procedureArrow right
