- Test the Platform Overload System - All Models (if equipped), Except ALC1000, S-60HC, S-80XC, S-85XC and Z-45XC Models

Genie specifications require that this procedure be performed annually OR when the machine fails to lift the maximum rated load

Testing the platform overload system regularly is essential to safe machine operation. Continued use of an improperly operating platform overload system could result in the system not sensing an overloaded platform condition. Machine stability could be compromised resulting in the machine tipping over

This maintenance procedure applies to the following models: S-40, S-45, S-60, S-65, S-80, S-85, Z-45/25 (J), Z-51/30J, Z-30/20N (RJ), Z-34/22, Z-34/22 (N), Z-34/22 IC, Z-40/23N (RJ), Z-45/25 (J) DC, 2-45/25 (J) Bi-Energy, Z-60 DC/FE, Z-62/40 and models equipped with the 340 kg capacity option

Note: Perform this procedure with the boom fully retracted and in the stowed position and with the machine on a firm, level surface

1. Remove all weight, tools, accessories and equipment from the platform

Note: Failure to remove all weight, tools and accessories from the platform will result in an inaccurate test

2 Engine Models: Turn the key switch to ground control and pull out the red Emergency Stop button to the on position at both the ground and platform controls. Start the engine from the ground controls and level the platform. Do not turn the engine off

DC Models: Turn the key switch to ground controls and pull out the red Emergency Stop button to the on position at both the ground and platform controls. Level the platform

Check for leaks Oil, fuel and coolant systems

Clean/replace air cleaner element

Check electrical wiring for chafing or damage

- Confirm the Proper Brake Configuration

1. Locate the drive hub disconnect cap

2. Check each drive hub disconnect cap to be sure it is in the engaged position

Collision hazard. Be sure that the machine is not in free-wheel or partial free-wheel configuration

Refer to maintenance procedure, Confirm the Proper Brake Configuration

Note: Select a test area that is firm, level and free of obstructions

1. Mark a test line on the ground for reference

- Check the Drive Hub Oil Level and Fastener Torque

Failure to maintain proper drive hub oil levels may cause the machine to perform poorly and continued use may cause component damage

1. Drive the machine to rotate the hub until the plugs are located one on top and the other at 90 degrees

2. Remove the plug located at 90 degrees and check the oil level

Result: The oil level should be even with the bottom of the plug hole

3. If necessary, remove the top plug and add oil until the oil level is even with the bottom of the side plug hole. 4. Install the plug(s) into the drive hub

5. Check the torque of the drive hub mounting bolts. Refer to Specifications, Machine Torque Specifications

6. Repeat this procedure for each drive hub

- Inspect the Electrical Contactor

Z-30N, 2-33, Z-34, Z-40 and Z-45 models:

1. Remove the drive chassis cover from the non-steer end of the machine and locate the electrical contactors)

2. Locate the electrical contactor mounted on the fuse bracket

Visually inspect the contact points of the contactor for the following items:
