Genie Genie Articulated Boom Lift S-105 S-105

- Test the Drive Speed - Stowed Position

Note: Perform this procedure with the machine on a firm, level surface that is free of obstructions

Note: Perform this procedure with the machine in the stowed position

1. Create start and finish lines by marking two lines on the ground 40 feet / 12.2 m apart

2. Choose a point on the machine (i.e., contact patch of a tire) as a visual reference for use when crossing the start and finish lines

3. Bring the machine to top drive speed before reaching the start line. Begin timing when your reference point on the machine crosses the start line

4. Continue at full speed and note the time when the machine reference point crosses the finish line. Refer to Specifications, Drive Speed Specifications

- Test the Drive Speed - Raised or Extended Position

1. Create start and finish lines by marking two lines on the ground 40 feet / 12.2 m apart

- Inspect the Tires, Wheels and Lug Nut Torque

Bodily injury hazard. An over-inflated tire can explode and could cause death or serious injury

Tip-over hazard. Do not use temporary flat tire repair products

Note: The tires on some machines are foam-filled or solid rubber and do not need air added to them

1. Check all tire treads and sidewalls for cuts, cracks, punctures and unusual wear

2. Check each wheel for damage, bends and cracked welds

3. Check each lug nut for proper torque. Refer to Specifications, Machine Specifications

- Check oil, fuel, and coolant systems for leaks

- Clean/replace air cleaner element

- Replace engine oil and filter

- Test the Emergency Power System (excludes ALC-600 and ALC-1000 Models)

1. Turn the key switch to ground control and pull out the red Emergency Stop button to the on position at both the ground and platform controls

2. At the ground controls, break the security tie and lift the emergency power switch cover (if equipped)

3. Simultaneously hold the emergency power switch on and operate each boom function through a partial cycle

• Result: All boom functions operate

4. Close the emergency power switch cover and secure the cover with a security tie (if equipped)

5 Turn the key switch to platform controls

6. At the platform controls, break the security tie and lift the emergency power switch cover (if equipped). 7. Press down on the foot switch and simultaneously hold the emergency power switch on and operate each boom function through a partial cycle

• Result: All boom functions operate

Required maintenance procedures and additional engine information are available in the manufacturer's manuals. Refer to Specifications, Engine Operator and Maintenance Manuals

Perkins Models, every 4000 hours (p.171):

• Aftercooler core - clean/test

GM 3.0L, every 5000 hours (p.172):

• Cooling system coolant - replace

Perkins 1104D-44T, every 6000 hours, (p.172)

• Cooling system coolant extender (ELC) - add
