Caterpillar Excavator 330GC

Cooling System Coolant Sample (Level 2) - Obtain

Refer to Operation and Maintenance Manual, “Cooling System Coolant Sample (Level 1) - Obtain” for the guidelines for proper sampling of the coolant.

Sample obtained as close as possible to the recommended sampling interval?

Supplies for collecting samples can be obtained from your Cat dealer.

Sample submitted for Level 2 analysis?

For additional information about coolant analysis, refer to Special Publication, SEBU6250, “Caterpillar Machine Fluids Recommendations” or consult your Cat dealer.

Sign off on the coolant sample collection and analysis

WARNING: Hot oil and hot components can cause personal injury. Do not allow hot oil or hot components to contact skin

1. Position one final drive so that oil drain plug (2) is at the bottom.

Note: Refer to Operation and Maintenance Manual, “General Hazard Information” for information on Containing Fluid Spillage.

2. Remove drain plug (2) and level plug (1). Allow the oil to drain into a suitable container.

3. Clean the plugs and inspect the O-ring seals. If wear or damage is evident, replace the drain plug, the level plug, and/or the O-ring seals.

5. Fill the final drive to the bottom of the opening on level plug (1). See Operation and Maintenance Manual, “Lubricant Viscosities” and Operation and Maintenance Manual, “Capacities (Refill)”.

Note: If the oil fills slowly, the fill hole may be blocked by the planetary gear. Rotate the final drive to move the planetary gear away from the fill hole.

Cooling System Coolant (ELC) - Change

WARNING: Personal injury can result from hot coolant, steam and alkali.

At operating temperature, engine coolant is hot and under pressure. The radiator and all lines to heaters or the engine contain hot coolant or steam. Any contact can cause severe burns.

Remove cooling system pressure cap slowly to relieve pressure only when engine is stopped and cooling system pressure cap is cool enough to touch with your bare hand.

Do not attempt to tighten hose connections when the coolant is hot, the hose can come off causing burns.

Cooling System Coolant Additive contains alkali. Avoid contact with skin and eyes.

NOTICE: Do not change the coolant until you read and understand the cooling system information in Special Publication, SEBU6250, “Caterpillar Machine Fluids Recommendations”. Failure to do so could result in damage to the cooling system components.

Mixing ELC with other products will reduce the effectiveness of the coolant.

Warning: Personal injury can result from hot coolant, steam and alkali.

At operating temperature, engine coolant is hot and under pressure.

Do not attempt to tighten hose connections when the coolant is hot, the hose can come off causing burns.

Cooling System Coolant Additive contains alkali. Avoid contact with skin and eyes.

Cooling System Coolant Level - Check

Fuel System Water Separator - Drain

Fuel Tank Water and Sediment - Drain

Hydraulic System Oil Level - Check

Cat HYDO Advanced Oil Change Interval

Procedure to Change the Hydraulic Oil

Sign off on the maintenance procedure
