Maintenance Plans for Andco Actuators Linear Electric Actuator Model 7210T

Integrate maintenance plans directly into your work orders in MaintainX.

Posi-Tork Ball Screw Actuator Disassembly

Check mark

Safety Precautions

Check mark

Disconnect all electrical power before removing covers of either position or thrust switch compartments.

Check mark

Ensure service personnel are licensed/trained and authorized.

Check mark

Disassembly Steps

Check mark

Remove compartment covers

Check mark

Disconnect and mark leads on the geared position limit switch and thrust switch.

Check mark

Remove pipe plug (23) to allow vent air into the housing.

Check mark

Remove limit switch assembly by removing hardware and rotating the switch assembly.

Check mark

Remove o-ring (55) and thrust switch assembly.

Run this procedureArrow right

Gear Box Assembly Dissassembly

Check mark

Safety Precautions

Check mark

Disconnect all electrical power to the actuator

Check mark

Wear approved Personnel Protective Equipment (PPE)

Check mark

Ensure service personnel are licensed/trained and authorized

Check mark

Use assistance when moving or lifting to avoid injury

Check mark

Disassembly Procedure

Check mark

Remove the position and torque limit switch compartment covers

Check mark

Disconnect the electrical power leads to the motor

Check mark

Remove the four fasteners retaining motor end bell and stator

Run this procedureArrow right

High Potential Testing

Check mark

Ensure no motor control cards are present

Check mark

Select the voltage setting for the appropriate motor voltage

Check mark

Set the test equipment to the selected voltage

Check mark

Contact each test point with the test equipment ground wire on the gear case plate

Check mark

Verify the actuator withstands the applied voltage for one second per test point without breakdown

Check mark

Note on motor power circuits testing

Check mark

Test motor power circuits based on motor voltage (AC)

Check mark

Apply DC voltage at 1.414 times the specified AC voltage for dielectric strength tests

Check mark

Refer to wiring diagram for test points

Run this procedureArrow right

Geared Position Limit Switch Adjustment

Check mark

Preparation

Check mark

Disconnect all electrical power to actuator

Check mark

Remove the position limit switch compartment cover (51)

Check mark

Remove the motor pipe plug (100)

Check mark

Actuator Shaft Adjustment

Check mark

Rotate the shaft clockwise to extend the actuator shaft

Check mark

Are the rotor (#36-1) contact fingers closed?

Check mark

Adjust rotor (#36-1) contact fingers

Check mark

Push and turn the slotted shaft '1' clockwise until the rotor turns to open the contacts

Run this procedureArrow right

Brake Replacement

Check mark

Safety Precautions

Check mark

Disconnect all electrical power to the actuator

Check mark

Ensure surface is cool before proceeding

Check mark

Brake Removal

Check mark

Remove the brake cover from the motor end bell

Check mark

Disconnect the coil power wires from the terminal strip

Check mark

Remove the brake assembly

Check mark

Brake Replacement

Check mark

Install the brake assembly by reversing the removal procedure

Run this procedureArrow right
